Specifications
Box size
1
Number of handles
4
Position of handles
A,B,C,D
Cover
Yes
Wall type
closed
Inner width
365 mm
Inner height
192 mm
Inner length
565 mm
Lettering
without
Foam inlay
No
Dividers
without division
incl. premium tools
No
Weight
4.74 kg
Transport dimensions
605 x 400 x 220 mm, 4.74 kg
Business division
MUNK Rettungstechnik
Article no.
114030
Information
- Stackable aluminium transport case with hinged lid
- Produced in accordance with DIN 14880
- High material strength and corrosion resistance
- Stackable thanks to all-round edge profile
- All-round seal in the edge profile to protect against dust and moisture
- Smooth side walls with spot-welded vertical seam
- Spring-loaded carry handles at different positions
- Permissible load: 105 kg
- Corporate certification: ISO 9001
- Corporate certification: EN 1090
- Corporate certification: EcoVadis
- RoHS
- REACH
- The MUNK Group complies with a Code of Conduct
- The Supply Chain Act does not apply due to our size
- The materials used are listed in the technical specification
- Resource-saving production: own photovoltaic systems
- Energy-efficient consumption during production: LED lighting
- Repairability, durability and quality: 15-year warranty on series products made in Germany
- Recyclability: Our products are mostly made of aluminium, steel or wood and can be fed directly into the recycling process.
- Socially acceptable working conditions in production: fair wages, gender equality
- Economical and recyclable packaging: no use of polystyrene, predominantly use of wood and cardboard, small amounts of plastic
- No health hazards for the users
Safety. Made in Germany.
Comparison table
| Product name | Case with lid Size 1 | Case with lid Size 2 | Case with lid Size 3 | Case with lid Size 4 | Case with lid Size 5 | Case with lid Size 6 |
|---|---|---|---|---|---|---|
| Box size | 1 | 2 | 3 | 4 | 5 | 6 |
| Number of handles | 4 | 4 | 3 | 3 | 3 | 4 |
| Position of handles | A,B,C,D | A,B,D,E | A,B,D | A,B,D | B,D,E | A,B,C,D |
| Cover | Yes | Yes | Yes | Yes | Yes | Yes |
| Wall type | closed | closed | closed | closed | closed | closed |
| Inner width | 365 mm | 265 mm | 365 mm | 265 mm | 230 mm | 365 mm |
| Inner height | 192 mm | 192 mm | 122 mm | 122 mm | 192 mm | 302 mm |
| Inner length | 565 mm | 365 mm | 565 mm | 365 mm | 565 mm | 765 mm |
| Lettering | without | without | without | without | without | without |
| Foam inlay | No | No | No | No | No | No |
| Dividers | without division | without division | without division | without division | without division | without division |
| incl. premium tools | No | No | No | No | No | No |
| Weight | 4.74 kg | 3 kg | 4.5 kg | 2.5 kg | 4 kg | 6.5 kg |
| Transport dimensions | 605 x 400 x 220 mm, 4.74 kg | 405 x 305 x 225 mm, 3 kg | 605 x 400 x 156 mm, 4.5 kg | 400 x 300 x 152 mm, 2.5 kg | 597 x 264 x 222 mm, 4 kg | 800 x 398 x 330 mm, 6.5 kg |
| Business division | MUNK Rettungstechnik | MUNK Rettungstechnik | MUNK Rettungstechnik | MUNK Rettungstechnik | MUNK Rettungstechnik | MUNK Rettungstechnik |
| Article no. | 114030 | 114031 | 114032 | 114033 | 114034 | 114035 |
Technical changes and price changes reserved. Dimensions and weights are approximate values. Liability for errors and mistakes excluded. Illustrations similar, some illustrations show special equipment. Preview images are representative of a product family and may therefore differ visually from the actual product you are looking for, e.g. in terms of number of steps or material.
