Order no.
: 036325
Platform ladder made of GRP / aluminium, folding and mobile, with GRP handrail
€ 3,202.00
RRP without VAT
Specifications
Working height
3.15 m
Step design
Steps
Number of steps/rungs
5 steps
Platform included as step
Yes
Platform height
1.17 m
Platform length
650 mm
Platform width
600 mm
Step depth
80 mm
Step/Rung distance
235 mm
Height
2.17 m
Base spread
1.4 m
Inclination
70 °
Outer width
650 mm
Stabiliser width
1 m
Depth of side-rails
73 mm
Depth of side-rails, support
58 mm
Castor diameter
125 mm
Max. load capacity
150 kg
Design type
Freestanding | Single-sided access | With chassis beam
Weight
33 kg
Transport dimensions
2710 x 750 x 220 mm, 33 kg
Predecessor product
036305
Business division
MUNK Günzburger Steigtechnik
Article no.
036325
Price
€ 3,202.00
Information
- Platform ladder made of reinforced fibre glass/aluminium
- Side-rails made of reinforced fibre glass rectangular tube profiles (min. 10 years ageing resistance)
- Grooved steps with a depth of 80 mm, made of aluminium
- 4-fold edged step-to-side-rail connection
- Spacious platform made of reinforced fibre glass grating (650 x 600 mm)
- With handrail on both sides, 3-sided, 1,000 mm high railing with knee and foot rails as well as safety rope
- nivello® ladder shoes with patented 2-axis inclination technology
- Support part with narrow stabiliser bar and Ø 125 mm fixed castors with locking device for quickly moving to a new location when folded out
- Folds for compact storage thanks to sturdy steel hinges
- Generous sized tool tray
- Step spacing: 235 mm
- Tested up to 1,000 V as per DIN EN 61478:2002 Clause 6.5.1 and A1:2004 Category 1 (corresponds to European Standard DIN EN 131-7)
- Ladder inclination: 70°
- Maximum load: 150 kg
- Delivery time: 15 days
- Suitable for working near or on live parts
- Note: Products with glass-fibre reinforced plastic content are non-returnable due to their sensitivity
- Corporate certification: ISO 9001
- Corporate certification: EN 1090
- Corporate certification: EcoVadis
- RoHS
- REACH
- The MUNK Group complies with a Code of Conduct
- The Supply Chain Act does not apply due to our size
- The materials used are listed in the technical specification
- Resource-saving production: own photovoltaic systems
- Energy-efficient consumption during production: LED lighting
- Repairability, durability and quality: 15-year warranty on series products made in Germany
- Recyclability: Our products are mostly made of aluminium, steel or wood and can be fed directly into the recycling process.
- Socially acceptable working conditions in production: fair wages, gender equality
- Economical and recyclable packaging: no use of polystyrene, predominantly use of wood and cardboard, small amounts of plastic
- No health hazards for the users
Scope of supply
- Ladder: 1 x
- Instructions for use and operation: 1 x
Safety. Made in Germany.
Comparison table
| Product name | Platform ladder made of GRP / aluminium, folding and mobile, with GRP handrail 5 steps | Platform ladder made of GRP / aluminium, folding and mobile, with GRP handrail 6 steps | Platform ladder made of GRP / aluminium, folding and mobile, with GRP handrail 7 steps | Platform ladder made of GRP / aluminium, folding and mobile, with GRP handrail 8 steps |
|---|---|---|---|---|
| Working height | 3.15 m | 3.4 m | 3.6 m | 3.85 m |
| Step design | Steps | Steps | Steps | Steps |
| Number of steps/rungs | 5 steps | 6 steps | 7 steps | 8 steps |
| Platform included as step | Yes | Yes | Yes | Yes |
| Platform height | 1.17 m | 1.4 m | 1.63 m | 1.87 m |
| Platform length | 650 mm | 650 mm | 650 mm | 650 mm |
| Platform width | 600 mm | 600 mm | 600 mm | 600 mm |
| Step depth | 80 mm | 80 mm | 80 mm | 80 mm |
| Step/Rung distance | 235 mm | 235 mm | 235 mm | 235 mm |
| Height | 2.17 m | 2.4 m | 2.63 m | 2.87 m |
| Base spread | 1.4 m | 1.5 m | 1.6 m | 1.7 m |
| Inclination | 70 ° | 70 ° | 70 ° | 70 ° |
| Outer width | 650 mm | 650 mm | 650 mm | 650 mm |
| Stabiliser width | 1 m | 1 m | 1.35 m | 1.35 m |
| Depth of side-rails | 73 mm | 73 mm | 73 mm | 73 mm |
| Depth of side-rails, support | 58 mm | 58 mm | 58 mm | 58 mm |
| Castor diameter | 125 mm | 125 mm | 125 mm | 125 mm |
| Max. load capacity | 150 kg | 150 kg | 150 kg | 150 kg |
| Design type | Freestanding | Single-sided access | With chassis beam | Freestanding | Single-sided access | With chassis beam | Freestanding | Single-sided access | With chassis beam | Freestanding | Single-sided access | With chassis beam |
| Weight | 33 kg | 35 kg | 38 kg | 41 kg |
| Transport dimensions | 2710 x 750 x 220 mm, 33 kg | 2980 x 750 x 247 mm, 35 kg | 3275 x 750 x 235 mm, 38 kg | 3530 x 750 x 240 mm, 41 kg |
| Predecessor product | 036305 | 036306 | 036307 | 036308 |
| Business division | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik |
| Article no. | 036325 | 036326 | 036327 | 036328 |
| Price | € 3,202.00 | € 3,293.00 | € 3,466.00 | € 3,571.00 |
| Buy online |
Product video
Technical changes and price changes reserved. Dimensions and weights are approximate values. Liability for errors and mistakes excluded. Illustrations similar, some illustrations show special equipment. Preview images are representative of a product family and may therefore differ visually from the actual product you are looking for, e.g. in terms of number of steps or material.
