Order no.
: 053103
Folding steps with retaining bracket
€ 396.00
RRP without VAT
Specifications
Working height
2.7 m
Height of the top step
640 mm
Top surface depth
205 mm
Top surface width
360 mm
Step/Platform surface
Aluminium corrugated
Non-slip class
R9
Number of steps/rungs
3 steps
Platform included as step
Yes
Step width
360 mm
Step depth
205 mm
Height
1.26 m
Base spread
820 mm
Outer width
550 mm
Max. load capacity
150 kg
Material
Aluminium
Weight
10 kg
Transport dimensions
1100 x 570 x 140 mm, 10 kg
Business division
MUNK Günzburger Steigtechnik
Article no.
053103
Price
€ 396.00
Information
- Aluminium folding steps
- Stable and smooth-running folding mechanism
- Design with strong double slide-rails
- 205 mm deep steps with grooves for a secure footing
- Top tread area: 360 x 205 mm
- Easy to transport, compact storage
- Non-slip plastic shoes
- Foldable retaining bracket with practical storage tray
- Just 125 mm deep when folded
- Maximum load: 150 kg
- These products are covered by the statutory warranty
- Corporate certification: ISO 9001
- Corporate certification: EN 1090
- Corporate certification: EcoVadis
- RoHS
- REACH
- The MUNK Group complies with a Code of Conduct
- The Supply Chain Act does not apply due to our size
- The materials used are listed in the technical specification
- Resource-saving production: own photovoltaic systems
- Energy-efficient consumption during production: LED lighting
- Repairability, durability and quality: 15-year warranty on series products made in Germany
- Recyclability: Our products are mostly made of aluminium, steel or wood and can be fed directly into the recycling process.
- Socially acceptable working conditions in production: fair wages, gender equality
- Economical and recyclable packaging: no use of polystyrene, predominantly use of wood and cardboard, small amounts of plastic
- No health hazards for the users
Scope of supply
- Step stool: 1 x
- Retaining bracket: 1 x
- Instructions for use and operation: 1 x
Safety. Made in Germany.
Comparison table
| Product name | Folding steps with retaining bracket 3 steps | Folding steps with retaining bracket 4 steps | Folding steps with retaining bracket 5 steps |
|---|---|---|---|
| Working height | 2.7 m | 2.9 m | 3.1 m |
| Height of the top step | 640 mm | 860 mm | 1.1 m |
| Top surface depth | 205 mm | 205 mm | 205 mm |
| Top surface width | 360 mm | 360 mm | 360 mm |
| Step/Platform surface | Aluminium corrugated | Aluminium corrugated | Aluminium corrugated |
| Non-slip class | R9 | R9 | R9 |
| Number of steps/rungs | 3 steps | 4 steps | 5 steps |
| Platform included as step | Yes | Yes | Yes |
| Step width | 360 mm | 360 mm | 360 mm |
| Step depth | 205 mm | 205 mm | 205 mm |
| Height | 1.26 m | 1.48 m | 1.72 m |
| Base spread | 820 mm | 1.1 m | 1.39 m |
| Outer width | 550 mm | 570 mm | 590 mm |
| Max. load capacity | 150 kg | 150 kg | 150 kg |
| Material | Aluminium | Aluminium | Aluminium |
| Weight | 10 kg | 12 kg | 15 kg |
| Transport dimensions | 1100 x 570 x 140 mm, 10 kg | 1415 x 590 x 130 mm, 12 kg | 1695 x 620 x 130 mm, 15 kg |
| Business division | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik |
| Article no. | 053103 | 053104 | 053105 |
| Price | € 396.00 | € 486.00 | € 597.00 |
| Buy online |
Product video
Technical changes and price changes reserved. Dimensions and weights are approximate values. Liability for errors and mistakes excluded. Illustrations similar, some illustrations show special equipment. Preview images are representative of a product family and may therefore differ visually from the actual product you are looking for, e.g. in terms of number of steps or material.
