Specifications
Working height
3.15 m
Step design
Steps
Number of steps/rungs
5 steps
Platform included as step
Yes
Platform height
1.15 m
Platform length
650 mm
Platform width
600 mm
Step depth
80 mm
Step/Rung distance
235 mm
Height
2.19 m
Total length folded
2.75 m
Base spread
1.4 m
Inclination
70 °
Outer width
650 mm
Stabiliser width
1 m
Depth of side-rails
73 mm
Depth of side-rails, support
58 mm
Width of side-rails
25 mm
Max. load capacity
150 kg
Design type
Freestanding | Single-sided access | With chassis beam
Weight
36.56 kg
Transport dimensions
2780 x 760 x 220 mm, 29 kg
Transport dimensions 2
1005 x 225 x 200 mm, 7.56 kg
Business division
MUNK Günzburger Steigtechnik
Article no.
052305
Price
€ 1,876.00
Information
- Platform ladder made of aluminium
- Stable rectangular tube side-rails
- Grooved steps with a depth of 80 mm
- Spacious platform with grooves for secure footing (650 x 600 mm)
- 4-fold edged step-to-side-rail connection
- With handrail on both sides, 3-sided, 1,000 mm high railing with knee and foot rails
- Folds for compact storage thanks to sturdy steel hinges
- Support part with stabilising stabiliser bar for high stability
- Integrated Ø 125 mm fixed castors with locking device for quick transportation when folded out
- nivello® ladder shoes with patented 2-axis inclination technology
- Generous sized tool tray
- Outer width: 650 mm (without stabiliser)
- Step spacing: 235 mm
- Ladder inclination: 70°
- Maximum load: 150 kg
- Corporate certification: ISO 9001
- Corporate certification: EN 1090
- Corporate certification: EcoVadis
- RoHS
- REACH
- The MUNK Group complies with a Code of Conduct
- The Supply Chain Act does not apply due to our size
- The materials used are listed in the technical specification
- Resource-saving production: own photovoltaic systems
- Energy-efficient consumption during production: LED lighting
- Repairability, durability and quality: 15-year warranty on series products made in Germany
- Recyclability: Our products are mostly made of aluminium, steel or wood and can be fed directly into the recycling process.
- Socially acceptable working conditions in production: fair wages, gender equality
- Economical and recyclable packaging: no use of polystyrene, predominantly use of wood and cardboard, small amounts of plastic
- No health hazards for the users
Scope of supply
- Ladder: 1 x
- Instructions for use and operation: 1 x
Certificates
Safety. Made in Germany.
Comparison table
| Product name | Platform ladder folding and mobile 5 steps | Platform ladder folding and mobile 6 steps | Platform ladder folding and mobile 7 steps | Platform ladder folding and mobile 8 steps | Platform ladder folding and mobile 10 steps | Platform ladder folding and mobile 12 steps | Platform ladder folding and mobile 14 steps |
|---|---|---|---|---|---|---|---|
| Working height | 3.15 m | 3.4 m | 3.6 m | 3.85 m | 4.3 m | 4.8 m | 5.25 m |
| Step design | Steps | Steps | Steps | Steps | Steps | Steps | Steps |
| Number of steps/rungs | 5 steps | 6 steps | 7 steps | 8 steps | 10 steps | 12 steps | 14 steps |
| Platform included as step | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Platform height | 1.15 m | 1.38 m | 1.61 m | 1.84 m | 2.3 m | 2.77 m | 3.23 m |
| Platform length | 650 mm | 650 mm | 650 mm | 650 mm | 650 mm | 650 mm | 650 mm |
| Platform width | 600 mm | 600 mm | 600 mm | 600 mm | 600 mm | 600 mm | 600 mm |
| Step depth | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Step/Rung distance | 235 mm | 235 mm | 235 mm | 235 mm | 235 mm | 235 mm | 235 mm |
| Height | 2.19 m | 2.42 m | 2.65 m | 2.88 m | 3.35 m | 3.81 m | 4.28 m |
| Total length folded | 2.75 m | 3 m | 3.25 m | 3.5 m | 4 m | 4.5 m | 5 m |
| Base spread | 1.4 m | 1.5 m | 1.6 m | 1.7 m | 1.95 m | 2.2 m | 2.4 m |
| Inclination | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Outer width | 650 mm | 650 mm | 650 mm | 650 mm | 650 mm | 650 mm | 650 mm |
| Stabiliser width | 1 m | 1 m | 1.35 m | 1.35 m | 1.7 m | 1.9 m | 1.95 m |
| Depth of side-rails | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm |
| Depth of side-rails, support | 58 mm | 58 mm | 58 mm | 58 mm | 58 mm | 58 mm | 58 mm |
| Width of side-rails | 25 mm | 25 mm | 25 mm | 25 mm | 25 mm | 25 mm | 25 mm |
| Max. load capacity | 150 kg | 150 kg | 150 kg | 150 kg | 150 kg | 150 kg | 150 kg |
| Design type | Freestanding | Single-sided access | With chassis beam | Freestanding | Single-sided access | With chassis beam | Freestanding | Single-sided access | With chassis beam | Freestanding | Single-sided access | With chassis beam | Freestanding | Single-sided access | With chassis beam | Freestanding | Single-sided access | With chassis beam | Freestanding | Single-sided access | With chassis beam |
| Weight | 36.56 kg | 37.56 kg | 42.58 kg | 44.08 kg | 48.6 kg | 54.06 kg | 74.8 kg |
| Transport dimensions | 2780 x 760 x 220 mm, 29 kg | 3040 x 760 x 220 mm, 30 kg | 3290 x 760 x 220 mm, 34 kg | 3520 x 760 x 220 mm, 35.5 kg | 4020 x 760 x 220 mm, 39 kg | 4530 x 760 x 220 mm, 44 kg | 5020 x 760 x 220 mm, 47 kg |
| Transport dimensions 2 | 1005 x 225 x 200 mm, 7.56 kg | 1005 x 225 x 200 mm, 7.56 kg | 1360 x 225 x 200 mm, 8.58 kg | 1360 x 225 x 200 mm, 8.58 kg | 1710 x 225 x 200 mm, 9.6 kg | 1915 x 225 x 200 mm, 10.06 kg | 1965 x 225 x 200 mm, 27.8 kg |
| Business division | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik |
| Article no. | 052305 | 052306 | 052307 | 052308 | 052310 | 052312 | 052314 |
| Price | € 1,876.00 | € 1,959.00 | € 2,050.00 | € 2,148.00 | € 2,247.00 | € 2,416.00 | € 2,924.00 |
| Buy online |
Product video
Sponsored by BG BAU
Specification subject to conditions; for the latest information please visit the BG BAU website (statutory accident insurance company for the construction and construction related services in Germany). Since 2014, the BG BAU has been promoting the purchase of platform ladders, step stools and ladder accessories with single-sided and double-sided access. All members of the BG BAU profit from this. This aims to prevent work accidents on building sites and improve ergonomic working practices. For more information by BG BAU, please visit: www.bgbau.de/service/angebote/arbeitsschutzpraemien
A brief overview of the subsidy and an overview of our eligible products can be found on our website under know-how.
Technical changes and price changes reserved. Dimensions and weights are approximate values. Liability for errors and mistakes excluded. Illustrations similar, some illustrations show special equipment. Preview images are representative of a product family and may therefore differ visually from the actual product you are looking for, e.g. in terms of number of steps or material.
