Specifications
Working height
2.95 m
Step design
Steps
Number of steps/rungs
4 steps
Platform included as step
Yes
Platform height
950 mm
Platform length
800 mm
Platform width
650 mm
Step depth
80 mm
Step/Rung distance
235 mm
Height
2.05 m
Base area
1.32 m
Inclination
70 °
Outer width
1.26 m
Stabiliser width
1.26 m
Depth of side-rails
73 mm
Width of side-rails
25 mm
Max. load capacity
150 kg
Design type
Freestanding | Single-sided access | With castors
Weight
31 kg
Transport dimensions
1210 x 730 x 370 mm, 31 kg
Business division
MUNK Günzburger Steigtechnik
Article no.
303104
Price
€ 970.00
Information
- Platform ladder made of aluminium
- Stable rectangular tube side-rails
- Grooved steps with a depth of 80 mm
- Spacious platform with grooves for secure footing (800 x 650 mm)
- 4-fold edged step-to-side-rail connection
- With handrail on both sides, 3-sided, 1,000 mm high railing with knee and foot rails
- Two Ø 100 mm castors for easily moving to a new location
- Easy to assemble (delivered unassembled)
- Stabiliser bars for high stability
- Outer width: 650 mm (without stabiliser)
- Ladder inclination: 70°
- Maximum load: 150 kg
- Corporate certification: ISO 9001
- Corporate certification: EN 1090
- Corporate certification: EcoVadis
- RoHS
- REACH
- The MUNK Group complies with a Code of Conduct
- The Supply Chain Act does not apply due to our size
- The materials used are listed in the technical specification
- Resource-saving production: own photovoltaic systems
- Energy-efficient consumption during production: LED lighting
- Repairability, durability and quality: 15-year warranty on series products made in Germany
- Recyclability: Our products are mostly made of aluminium, steel or wood and can be fed directly into the recycling process.
- Socially acceptable working conditions in production: fair wages, gender equality
- Economical and recyclable packaging: no use of polystyrene, predominantly use of wood and cardboard, small amounts of plastic
- No health hazards for the users
Scope of supply
- Ladder: 1 x
- Castor (enclosed separately): 2 x
- Handrail (enclosed separately): 2 x
- Instructions for use and operation: 1 x
Certificates
Safety. Made in Germany.
Comparison table
| Product name | Platform ladder with castors 4 steps | Platform ladder with castors 5 steps | Platform ladder with castors 6 steps | Platform ladder with castors 7 steps | Platform ladder with castors 8 steps |
|---|---|---|---|---|---|
| Working height | 2.95 m | 3.2 m | 3.45 m | 3.65 m | 3.9 m |
| Step design | Steps | Steps | Steps | Steps | Steps |
| Number of steps/rungs | 4 steps | 5 steps | 6 steps | 7 steps | 8 steps |
| Platform included as step | Yes | Yes | Yes | Yes | Yes |
| Platform height | 950 mm | 1.19 m | 1.43 m | 1.66 m | 1.9 m |
| Platform length | 800 mm | 800 mm | 800 mm | 800 mm | 800 mm |
| Platform width | 650 mm | 650 mm | 650 mm | 650 mm | 650 mm |
| Step depth | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Step/Rung distance | 235 mm | 235 mm | 235 mm | 235 mm | 235 mm |
| Height | 2.05 m | 2.29 m | 2.52 m | 2.76 m | 2.99 m |
| Base area | 1.32 m | 1.43 m | 1.53 m | 1.64 m | 1.74 m |
| Inclination | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Outer width | 1.26 m | 1.26 m | 1.26 m | 1.26 m | 1.26 m |
| Stabiliser width | 1.26 m | 1.26 m | 1.51 m | 1.51 m | 1.58 m |
| Depth of side-rails | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm |
| Width of side-rails | 25 mm | 25 mm | 25 mm | 25 mm | 25 mm |
| Max. load capacity | 150 kg | 150 kg | 150 kg | 150 kg | 150 kg |
| Design type | Freestanding | Single-sided access | With castors | Freestanding | Single-sided access | With castors | Freestanding | Single-sided access | With castors | Freestanding | Single-sided access | With castors | Freestanding | Single-sided access | With castors |
| Weight | 31 kg | 32.5 kg | 37 kg | 38.5 kg | 39 kg |
| Transport dimensions | 1210 x 730 x 370 mm, 31 kg | 1290 x 730 x 395 mm, 32.5 kg | 1820 x 725 x 370 mm, 37 kg | 1820 x 730 x 370 mm, 38.5 kg | 1915 x 730 x 390 mm, 39 kg |
| Business division | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik |
| Article no. | 303104 | 303105 | 303106 | 303107 | 303108 |
| Price | € 970.00 | € 1,021.00 | € 1,061.00 | € 1,115.00 | € 1,164.00 |
| Buy online |
Sponsored by BG BAU
Specification subject to conditions; for the latest information please visit the BG BAU website (statutory accident insurance company for the construction and construction related services in Germany). Since 2014, the BG BAU has been promoting the purchase of platform ladders, step stools and ladder accessories with single-sided and double-sided access. All members of the BG BAU profit from this. This aims to prevent work accidents on building sites and improve ergonomic working practices. For more information by BG BAU, please visit: www.bgbau.de/service/angebote/arbeitsschutzpraemien
A brief overview of the subsidy and an overview of our eligible products can be found on our website under know-how.
Technical changes and price changes reserved. Dimensions and weights are approximate values. Liability for errors and mistakes excluded. Illustrations similar, some illustrations show special equipment. Preview images are representative of a product family and may therefore differ visually from the actual product you are looking for, e.g. in terms of number of steps or material.
