Order no.
: 012014
Step window cleaner’s ladder lower section with nivello® stabiliser and clip-step R13
€ 238.00
RRP without VAT
Specifications
Ladder length
770 mm
Number of steps/rungs
2 steps
Step depth
80 mm
Step/Rung distance
235 mm
Upper outer width
364 mm
Lower outer width
900 mm
Stabiliser width
900 mm
Inclination
70 °
Depth of side-rails
73 mm
Width of side-rails
25 mm
Max. load capacity
120 kg
Design type
To lean against
BG BAU supported
Yes
Weight
3.23 kg
Transport dimensions
805 x 905 x 97 mm, 3.228 kg
Business division
MUNK Günzburger Steigtechnik
Article no.
012014
Price
€ 238.00
Information
- Step window cleaner's ladder made of aluminium
- Stable rectangular tube side-rails
- Grooved steps with a depth of 80 mm
- clip-step R13 step padding for certified non-slip protection
- 4-fold edged step-to-side-rail connection
- Secure push-fit connection with additional hook lock
- Upper ladder with castors and abrasion-resistant contact rubber pad with wedge cut-out
- Lower ladder with nivello® stabiliser for extra stability and safe ascent (enclosed separately)
- Depending on the selection, a maximum of four individual parts can be combined, as the standing height of 5.0 m must not be exceeded
- Step spacing: 263 mm
- Ladder inclination: 70°
- Maximum load: 120 kg
- Corporate certification: ISO 9001
- Corporate certification: EN 1090
- Corporate certification: EcoVadis
- RoHS
- REACH
- The MUNK Group complies with a Code of Conduct
- The Supply Chain Act does not apply due to our size
- The materials used are listed in the technical specification
- Resource-saving production: own photovoltaic systems
- Energy-efficient consumption during production: LED lighting
- Repairability, durability and quality: 15-year warranty on series products made in Germany
- Recyclability: Our products are mostly made of aluminium, steel or wood and can be fed directly into the recycling process.
- Socially acceptable working conditions in production: fair wages, gender equality
- Economical and recyclable packaging: no use of polystyrene, predominantly use of wood and cardboard, small amounts of plastic
- No health hazards for the users
Scope of supply
- Ladder lower section: 1 x
- Stabiliser (enclosed separately): 1 x
- Instructions for use and operation: 1 x
Safety. Made in Germany.
Comparison table
| Product name | Step window cleaner’s ladder lower section with nivello® stabiliser and clip-step R13 2 steps | Step window cleaner’s ladder lower section with nivello® stabiliser and clip-step R13 6 steps | Step window cleaner’s ladder lower section with nivello® stabiliser and clip-step R13 5 steps |
|---|---|---|---|
| Ladder length | 770 mm | 1.87 m | 1.59 m |
| Number of steps/rungs | 2 steps | 6 steps | 5 steps |
| Step depth | 80 mm | 80 mm | 80 mm |
| Step/Rung distance | 235 mm | 235 mm | 235 mm |
| Upper outer width | 364 mm | 364 mm | 364 mm |
| Lower outer width | 900 mm | 900 mm | 900 mm |
| Stabiliser width | 900 mm | 900 mm | 900 mm |
| Inclination | 70 ° | 70 ° | 70 ° |
| Depth of side-rails | 73 mm | 73 mm | 73 mm |
| Width of side-rails | 25 mm | 25 mm | 25 mm |
| Max. load capacity | 120 kg | 120 kg | 120 kg |
| Design type | To lean against | To lean against | To lean against |
| BG BAU supported | Yes | Yes | Yes |
| Weight | 3.23 kg | 8.41 kg | 6.1 kg |
| Transport dimensions | 805 x 905 x 97 mm, 3.228 kg | 1937 x 905 x 95 mm, 8.41 kg | 1647 x 905 x 97 mm, 6.104 kg |
| Business division | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik |
| Article no. | 012014 | 012011 | 012017 |
| Price | € 238.00 | € 396.00 | € 350.00 |
| Buy online |
Product video
Sponsored by BG BAU
Specification subject to conditions; for the latest information please visit the BG BAU website (statutory accident insurance company for the construction and construction related services in Germany). Since 2014, the BG BAU has been promoting the purchase of platform ladders, step stools and ladder accessories with single-sided and double-sided access. All members of the BG BAU profit from this. This aims to prevent work accidents on building sites and improve ergonomic working practices. For more information by BG BAU, please visit: www.bgbau.de/service/angebote/arbeitsschutzpraemien
A brief overview of the subsidy and an overview of our eligible products can be found on our website under know-how.
EuroTest Prize 2019
for outstanding achievements in occupational health and safety
Technical changes and price changes reserved. Dimensions and weights are approximate values. Liability for errors and mistakes excluded. Illustrations similar, some illustrations show special equipment. Preview images are representative of a product family and may therefore differ visually from the actual product you are looking for, e.g. in terms of number of steps or material.
